4040 SMD RGB/RGBW 90-120Leds/m
The 4040 colorful RGB light strip uses high-brightness 4040 RGB LED chips, with a variety of LED quantities to choose from.
It has rich colors and can achieve a variety of color changes.
Supports DC 12V or 24V power supply, low power consumption, and compatible with a variety of RGB controllers. Using flexible FPC circuit board, easy to bend and install.
Suitable for decorative lighting, atmosphere creation, commercial displays, entertainment venues, etc.
Specification:
- 3.6W/FT(12W/M)
- 32.8ft(10m) max.run length ( standard model)
- 120 degree beam angle
- IP20/65/ 67/IP68 rating
- 24V input
- Ambient Temperature -25℃~+45℃
- Storage Temperature -25℃~+60℃
Specifications
| Product Model | LEDs/m | Max Power(w/m) | PCB Width(mm) | Color Temperature | Luminous efficacy(LM/W) | Voltage(V) | Cut Length(mm) | CRI |
| WP-4040RGB-90D-8 | 90 | 12 | 8 | RGB | 35 | 24 | 55.5 | / |
| WP-4040RGB-120D-8 | 120 | 12 | 8 | RGB | 33 | 24 | 50 | / |
| WP-4040RGB-120D-8 | 120 | 12 | 10 | RGB | 40 | 24 | 50 | / |
| WP-4040RGBW-120D-10 | 120 | 14.4 | 10 | RGBW | 55 | 24 | 50 | / |
| WP-4040RGBW-120D-12 | 120 | 14.4 | 12 | RGBW | 55 | 24 | 50 | / |
