WS2813 5050RGB 30-144Leds 10mm
The WS2813 RGB light strip is a high-performance smart light strip that uses LED and a built-in control chip to support independent adjustment of four colors: red, green, blue and white.
Its upgraded dual signal transmission design ensures that even if a single LED is damaged, the light strip can still work normally, enhancing reliability.
It supports dynamic effects and accurate color display suitable for home decoration, stage lighting, advertising display and other scenes, and provides flexible light effect solutions.
Specification：
- 8.6W/FT(28.8W/M)
- 1LEDs per pixel(18 LEDs/ft,60 LEDs/m)
- 32.8ft(10m) max.run length ( standard model)
- 120 degree beam angle
- Controlled with WS2813
- IP20/65/ 67 /68 rating
- 5V input
- Ambient Temperature -25℃~+45℃
- Storage Temperature -25℃~+60℃
Specifications
| Product Model | LEDs/m | IC Protocol | Pixels/m | Voltage(V) | Max Power(w/m) |
PCB Width(mm) |
Cut Length(mm) |
| WP-H5050RGB-30D-10 | 30 | WS2813 | 30 | 5 | 6 | 10 | 33.3 |
| WP-H5050RGB-60D-10 | 60 | WS2813 | 60 | 5 | 12 | 10 | 16.6 |
| WP-H5050RGB-96D-10 | 96 | WS2813 | 96 | 5 | 19.2 | 10 | 10.4 |
| WP-H5050RGB-144D-12 | 144 | WS2813 | 144 | 5 | 28.8 | 12 | 6.9 |
Application
